Used machines for sale
 Filters
Main brands:
, Consolid, FNB, Ralf Winter, Razi, Sulinox, Veolia, VIMA, Zegla
|
| Filters |
The industry uses a variety of filters for different purposes, depending on the type of process, substances to be filtered and specific requirements. Here are some common types of industrial filters:
Air Filters:
Bag filters
Cartridge Filters
Paper filters
Electrostatic filters
Water Filters:
Sand Filters
Activated carbon filters
Membrane filters (microfiltration, ultrafiltration, nanofiltration, reverse osmosis)
Disk filters
Oil Filters:
Cartridge Filters
Centrifugal filters
Magnetic Filters
Solid Particle Filters:
Press filters
Rotary Drum Filters
Basket Filters
Gas Filters:
Activated carbon filters
Ceramic filters
Fiberglass Filters
Chemical Process Filters:
Nutsche pressure filters
Plate and frame filters
Bag filters
Liquid Particle Filters:
Cartridge Filters
Screen filters
Gravity Filters
Biological Process Filters:
Aerobic biological filters
Anaerobic biological filters
Filters for Specific Materials:
Polymer filters
Metal filters
Ceramic filters
Filters for Specific Fluids:
Blood filters (for medical applications)
Hydraulic fluid filters
Transformer oil filters
These are just a few examples and the diversity of industrial filters is wide, varying according to the specific application and process requirements. Each type of filter is designed to handle certain types of contaminants and operating conditions. |
|
|
|
 |
Filter for industrial processes in stainless steel sparkler type.
Year: 2004.
Hydrostatic test: 10.0 KGFcm²
Maximum permitted working pressure: 7.0 KGFcm².
Volume: 300 L.... |
|
|
 |
Stainless steel filter bag.
Dust collector with shaking system.
Approximate measurements:
Overall height: 2600 mm.
Inner diameter: 410 mm.
Bottom diameter (outlet): 115 mm.
Distance from outlet to floor: 560 mm.
Side width: 820 m... |
|
|
 |
Brand: Razi, VIMA
Two industrial dust collectors.
Unity 1.
Brand: Razi.
Model: RZ - CP3BT.
With 3 H.P.
Voltage: 220V.
Frequency: 60 Hz.
Unit 2.
Dust collector.
Brand: VIMA.... |
|
|
 |
Brand: Consolid
Stainless steel bag.
Brand: Consolidated
Equipment in polished stainless steel 304.
This equipment can be combined with screw conveyors we have in stock, as well as other silos, powder mixers and feed line assembly.... |
|
|
 |
Brand: Zegla
Ground filter for beverages and liquids.
With vertical plates.
Brand: Zegla.
For 8,000 L.
Manufacturing Standard: ACS.
Stainless steel.
With filters.
With support for top and bottom cover.... |
|
|
 |
Filter sparkler.
Stainless steel.
Capacity: 50 liters.
With pump.... |
|
|
 |
Brand: Consolid
Silo for powder feeder.
Brand: Consolidated
Equipment in polished stainless steel 304.
With engine and exhaust.
With new filter set.
This equipment can be combined with screw conveyors we have in stock, as well as other silos, powder m... |
|
|
 |
Cabin with bag filters.
Dust collector.
Filter quantity: 25.
Approximate filter measurements:
Diameter 110 mm x 1860 mm Height.
Approximate external measurements for transport: (Height x Width x Length)
2600mm x 1200mm x 1200mm.
... |
|
|
 |
Brand: Zegla
Pre-layer filter for removing insoluble solids suspended in liquid media.
Capacity: 10000 liters per hour.
Manufacturer/brand: Zegla.
Year of manufacture: 2000.
Stoppage time: 7 years. Operating time: 17 years.
The pre-cap filter opera... |
|
|
 |
Brand: Ralf Winter
Filter for syrup and drinks diatomaceous earth in stainless steel.
Manufacturer: Ralph Winter.
Approximate capacity: 9,000 liters / hour.
For filtering simple syrup and beverages.
Year: 2014.
Self-cleaning equipment with vertical plate... |
|
|
 |
Softening filter.
Diameter 1300 mm.
cylindrical height 2.20 m.
Plate thickness 9 mm.
Number of crepines 70.
316 stainless steel crepes.
diameter of 50 mm.
height of 60 mm.
3/4 "thread.... |
|
|
 |
Water filter or pressure vessel type softening filter.
Number of crepe holes: 100.
Crepine dimensions: diameter 50 mm.
Diameter: 1800 mm.
Cylindrical height 4500 mm.
Side plate thickness: 12 mm.
Mirror thickness: 3/4 ".
crepines ... |
|
|
 |
Pressure vessel type softening filter.
Diameter: 1500 mm.
Side height (cylindrical): 2000 mm.
Side plate thickness: 12 mm.
Tops thickness 1/2 ".
Crepine fixing mirror: 12mm.
Number of crepes: 100.
Crepine: diameter 60 mm.
Heig... |
|
|
 |
Brand: Veolia
Industrial active carbon filter.
Brand: Veolia.
Useful volume: 20,000 L.
With 200 crepines.
Operating Pressure: 7kg.
8 mm plate.
Empty weight: 3,507 kg.
Production capacity in operation: 45 m³ each.
Application: Water filtrati... |
|
|
 |
Filter nucha.
Nucha filters are much needed equipment in places that perform the separation of solid and liquid elements from corrosive solutions.
There are various filter models, such as the pressure filter, the pressure filter with agitator a... |
|
|
 |
Capacity tank 120 liters.
With internal plates.
Filter Sparkler.... |
|
|
 |
Brand: Zegla
Syrup filter.
Manufacturer/brand: Zegla.
Approximate capacity: 6,000 liters per hour.
Weight: 617 kg.
Manufacturing standard: ACS.
Year: 1996.... |
|
|
 |
Brand: Zegla
Stainless steel dechlorinator filter for drinks.
Manufacturer/brand: Zegla.
Year: 1996.
Manufacturing standard: ACS.
Weight: 280 kg.... |
|
|
 |
Stainless steel polishing filter for drinks.
Manufacturer/brand: Zegla.
Year: 1996.
Weight: 86 kg.... |
|
|
 |
Dust collection system with bag filters.
Capacity: 15,000 m³ depending on the particles.
Brand: Elite Industrial Equipment.
Filter with 120 bag filters.
Equipment was used to collect soot from the burning of the boiler, filtering the air ... |
|
|
 |
Brand: Sulinox
Filter for stainless steel processes.
Brand name: Sulinox.
Year: 1999.
Diameter: 440 mm.
Cylindrical height: 330 mm.
Empty weight: 357 kg.
Operating weight: 507 kg.... |
|
|
 |
Brand: FNB
Dryer Filter nucha.
Vacuum dryer pressure filter.
Brand: FNB.
Filter liquid solid.
For extraction filtration and vacuum drying.
Hermetic system.
Filter surface from 0.07 to 15 m².
Process volumes: 19 L 15,000 L.
Operation by l... |
|
|
 |
Components: SEW
Rotary filter
1
SUPPLY DESCRIPTION 01 Rotary Drum vacuum filter type Belt with 350 ft. ² area,
dimensions Ø 8 x 14, predominant material 316 l stainless steel manufacturer Door Oliver.
2 BASIC SCOPE: Rotating Type vacuum Belt Filter Ø 8 x 1... |
|
|
|
|
