Used machines for sale
 Hammer mills
Main brands:
ABIS Machines, Braibanti, Carnevalli, Envitec, Hosokawa Micron, Imapi, Inmac, Jocar, Meteor, Netzsch, Nogueira, Tigre, Vieira
|
| Hammer mills |
A hammer mill is equipment used to reduce the size of solid materials through the collision between rotating hammers and the material to be ground. This type of mill is widely used in various industries to produce particles of controlled size. Let’s explore what a hammer mill is for and how it works:
What is it for:
Size Reduction: The main purpose of a hammer mill is to reduce the size of solid particles through grinding.
Production of Controlled Particles: It is used to produce particles of a controlled size from various materials, such as grains, foods, chemicals, minerals, among others.
Pre-grinding: In some applications, the hammer mill is used as part of a pre-grinding process, reducing the initial size of the material before other processes.
How it works:
Rotary Hammers:
The hammer mill consists of a rotor equipped with hammers that rotate at high speed. These hammers collide with the material to be ground.
Material Feeding:
The material to be ground is fed into the grinding chamber of the mill, usually through a hopper or other feeding device.
Impact and Collision:
As the rotor rotates, the hammers move at high speed, colliding with the material. This impact causes the particles to break and reduce their size.
Sieve or Output Grid:
The hammer mill usually has a sieve or outlet grid that controls the size of particles that can pass through. Smaller particles pass through the sieve, while larger particles are kept in the grinding chamber for further collisions.
Particle Size Control:
The size of the openings in the sieve or grid can be adjusted to control the size of the final particles.
Product Output:
The ground particles are discharged from the mill through the opening at the bottom.
Benefits:
Versatility: Can grind a wide variety of materials, from grains to industrial waste.
Grinding Efficiency: Provides efficient grinding, especially for hard materials.
Precise Particle Size Control: By adjusting the sieve or grid, it is possible to control the size of the particles produced.
Simplicity of Operation: In general, it is relatively easy to operate and maintain.
Hammer mills are commonly used in various industries, including agriculture, food, chemical and mining, where size reduction is required to produce particles of a specific size.
Some examples of industries and products for which hammer mills are commonly employed include:
Agricultural Industry:
Products: Grains (corn, wheat, rice), oilseeds.
Applications: Animal feed processing, feed production.
Food industry:
Products: Cereals, spices, herbs, grains.
Applications: Grinding ingredients for processed foods, ground spices.
Chemical industry:
Products: Various chemicals in powder form.
Applications: Production of fine chemicals, grinding of products for additive manufacturing.
Pharmaceutical industry:
Products: Active pharmaceutical ingredients (IFAs), excipients.
Applications: Grinding components for drug formulation.
Mining and Metallurgy Industry:
Products: Minerals, ores.
Applications: Preparation of ores for processing, production of fine powders.
Recycling Industry:
Products: Recyclable materials, industrial waste.
Applications: Grinding recyclable materials to produce recycled materials.
Biofuels Industry:
Products: Biomass, pellets.
Applications: Preparation of biomass for biofuel production, pellet grinding.
Pulp and Paper Industry:
Products: Wood, cellulose.
Applications: Preparation of raw material for paper production, size reduction of wood waste.
Plastics Industry:
Products: Plastic resins, recyclable materials.
Applications: Grinding resins for the production of plastic powders, recycling plastic materials.
Animal Nutrition Industry:
Products: Animal feed, supplements.
Applications: Animal feed processing, ingredient grinding.
Cosmetics and Personal Care Industry:
Products: Cosmetic ingredients.
Applications: Grinding ingredients for the production of cosmetics. |
|
|
|
 |
Hammer mill for sugar refining.
Made of carbon steel.
Includes a sieve for powdered sugar.
Three-phase motor with 5 HP and 3485 RPM.
Equipment weight: 450 kg.
Number of hammers: 20.
Approximate dimensions:
Height: 2.30 m.
Widt... |
|
|
 |
Brand: Tigre
Universal stainless steel hammer mill.
Manufacturer: Tiger.
Model: ML 20/5.
With filter and ventilation system.
Engine: 2 CV / rotation 800 RPM.
Approximate dimensions:
Height: 2.0 m.
Width: 800 mm.
Length: 1.0 m.
Mill Diam... |
|
|
 |
Hammer mill.
Engine: 60 hp.
Rotation: 3565 r.p.m.
Voltage: 220/380 v.
It was used for sugar milling.
Carbon steel equipment... |
|
|
 |
Brand: Carnevalli
Complete line for the production of PVC conduits.
Manufacturer: Carnevalli and Santa Maria.
Line composed of:
- Extruder.
- Bathtub.
- Puller.
- Carimbeira.
- Threader.
- Aggregator.
- Hammer Mill.
- Polycut.
- Coolin... |
|
|
 |
Brand: ABIS Machines, Jocar
Complete company / industry for coffee roasting and grinding.
Line for coffee roasting, grinding and packaging.
Approximate production: from 1500 to 2500 kilos a day.
Composed by:
- Coffee roaster.
Manufacturer: Play.
Model: Ecological.... |
|
|
 |
Hammer mill with table and 10 hp motor.
Capacity 10 kg / h.
Brand: Tiger.... |
|
|
 |
Used stainless steel hammer mill.
Equipment without engine.... |
|
|
 |
Brand: Hosokawa Micron
Hammer mill.
Brand: Hosokawa.
With 92 video-coated hammers.
Rotor diameter 500 mm.
Engine 50 hp.... |
|
|
 |
Brand: Tigre
Industrial hammer mill.
Capacity: 800 kg / h.
Brand: Tiger.
Engine: 20 CV.
Machine in carbon steel.... |
|
|
 |
Brand: Braibanti
For reprocesso breaker mill of masses being the trim your and curves.
Brand: Braibanti.
Year: 1988.
The reprocesso system consists of the equipment:
electric Hoist/bags/discharger mill.
Note: Without the drying system.... |
|
|
 |
Brand: Vieira
Industrial Hammer Mill.
Brand: Vieira.
Model: MCD 950.
With 100 hp engine.... |
|
|
 |
Brand: Inmac
Industrial mill for coffee.
Brand: Inmac.
Capacity: 500 kg / h.
With silo, motor, trawler.
Year: 1985.... |
|
|
 |
Brand: Meteor
Meteor brand sugar mill. Production: 900/hour
With filter through filter sleeve... |
|
|
 |
Brand: Tigre
Universal stainless steel hammer mill for fruit and pulp.
Manufacturer: Moinhos Tigre.
With sieve.
It has no electric motor.
Approximate capacity: up to 1 ton per hour.... |
|
|
 |
Brand: Nogueira
Hammer mill.
Brand: Walnut.
Model: DPM Junior.
With two axes with 3 knives each.
Engine: 3 hp.... |
|
|
 |
Stainless steel mill.
Engine: 5 hp.
Voltage: 380v.
Type: hammer mill.... |
|
|
 |
Brand: Tigre
Stainless steel hammer mill.
Brand: Tiger.
Engine: With 30 hp.
With 5 pulleys.
Mill plus support in carbon steel.
Support size:
Depth: 1,60m.
Width: 1.20m.
Mill body width: 47 cm.
From the mouth to the floor: 1.14m.... |
|
|
 |
Brand: Vieira
Hammer mill.
Brand: Scallop.
Model: MCS 280.
Year: 2019.
Engine 5 HP.
In carbon steel.
It was used to grind grain.
Belt reduction A7.
P.P.M: 6,000.
With silo and cyclone with filter.
Manufacturer Technical Information * ... |
|
|
 |
Brand: Vieira
Hammer mill for micronized grinding.
Manufacturer/brand: Vieira.
Model: MCS 280.
Power: 5 HP.
Developed for micronization of grains, cereals and spices.
Productivity from 30 kg / hour in micronized grinding with Ø 0.3 mm hole mill siev... |
|
|
 |
Brand: Indumak
Complete factory for flour production.
Composed by:
- Balance
- Pre cleaning (self performance)
- Storage of dry wheat with a capacity of 300 tons.
- Storage of wet wheat with a capacity of 20 tons.
- Silo for flour storage.
Capa... |
|
|
 |
Brand: Vieira
Hammer mill in 1020 carbon steel with white epoxy paint.
Manufacturer: Vieira.
Model: MCS 280.
Power: 5 hp.
For grinding grains, cereals and spices, as well as grinding pre-mix formulations and reprocess grinding.
Approximate capacity:... |
|
|
 |
Mill with 12 carbon steel hammers.
Manufacturer: Casa Renard.
With grinding system with 250 mm diameter rotor.
For grinding grain or bran products into small particles.
Motor: three-phase 2.2 Kw 3.0 CV.
Approximate dimensions:
Heigh... |
|
|
 |
Brand: Tigre
Hammer mill, in stainless steel, Tigre brand, complete (structure, filter bank and sieve), power 30 hp.... |
|
|
 |
Brand: Tigre
Hammer mill.
Stainless steel.
Engine: 15 HP.
Grinding with 20 hammers.
Tiger Brand.
Mill to grind sugar, grains, spices, seeds, chocolates, cereals, condiments, herb leaves and twigs, flour, corn, among others.
Especially designed f... |
|
|
 |
Hammer type mill.
2 cv-three-phase motor-1730 rpm.
With sieve 4 mm diameter hole.
Production of 100 to 150 kg hour.... |
|
|
 |
Brand: Envitec
Components: Siemens
-Mill called Envitec with screens of the company Mineralmaq.
-G28H1610-7HK33: Siemens engines/high performance three-phase induction motor V100L2
-
-electrical panel Camara with
-Par booking record.
... |
|
|
 |
Brand: Tigre
Hammer mill Tiger brand, without motor model EC-12... |
|
|
 |
Brand: Imapi
800 mm mill with 40 Hp engine,
1 Imapi brand Granulator saseg brand with motor 2 Hp... |
|
|
 |
Brand: Meteor
Hammer sugar mill.
Capacity: 1500 kg / hour approximately.
With reinforced steel table.
Without motor and electrical panel.
... |
|
|
 |
Brand: Netzsch
Grinding and refining system for sugar and solid products.
With Netzsch universal mill.
Powder filtration system.... |
|
|
|
|
