 Pan mixer
Main brands:
Ariete, Bonsucesso, Claumaq, Consolid, Dinapan, Imarvil, JHM, Klainox, Sew Eurodrive, Star Machine
|
| Pan mixer |
A horizontal paddle mixer is equipment used in industry to mix different materials, whether solid, liquid or pasty, homogeneously. These mixers are widely used in various industrial sectors, such as food, pharmaceuticals, chemicals, cosmetics and many others. Here is some information about the purpose and operation of a horizontal paddle mixer:
Goal:
Homogenization: The main purpose is to guarantee the homogeneous mixing of different components, ensuring the consistency and quality of the final products.
Ingredient Integration: Allows efficient integration of different ingredients, such as solid powders, viscous liquids, granules, among others.
Deagglomeration: Can help break down agglomerates of powders or granulated materials, promoting a more uniform mixture.
Sensitive Mixing: It is suitable for mixing materials sensitive to shear, where it is necessary to avoid damage or changes to components.
Operation:
Horizontal Paddles or Blades: The mixer has horizontal paddles or blades that are located inside a horizontal drum or container. These paddles are designed to move materials effectively.
Drum Rotation: The drum or container is usually placed in a horizontal position and is rotated to ensure that the paddles cover the full extent of the materials.
Paddle Movement: Paddles move materials in opposite directions or in specific patterns to ensure thorough mixing.
Discharge: After the mixing process, the mixer usually has a discharge system that allows efficient removal of the mixture to the next stage of the production process.
Precise Controls: Many horizontal mixers come equipped with precise controls that allow adjustments to rotation speed, mixing time and other parameters to meet process specifications.
Capacity and Design: Mixer capacity and design vary depending on specific industry needs. They can be found from laboratory models to large-scale industrial mixers.
Horizontal paddle mixers are a common choice in many industrial operations due to their efficiency in producing homogeneous mixtures across different industries. |
|
|
|
 |
Brand: Ariete, Dinapan
Stainless steel sigma mixer mixer.
Total estimated litre I calculate cylinder volume: 1,500 L / 1,600 L.
Bowl measurements considering cylinder volume: 1200 mm height by 1300 mm diameter.
Engine: WEG brand model 315 S / M.
Power and rotat... |
|
|
 |
Soap manufacturing line.
Approximate capacity: 500 kg/hour.
Composed of:
- Internal stainless steel paddle mixer.
Approximate capacity: 500 liters.
- Internal stainless steel soap extruder.
- With chiller | cold water unit bank.... |
|
|
 |
Components: WEG
Rotary tubular system with stainless steel mixing screw for applying oil and palatable agents to feed.
In the upper part: rotating stainless steel greasing tube drum for applying oil.
In the lower part: stainless steel mixing screw conveyor wit... |
|
|
 |
Stainless steel jacketed paddle mixer.
Approximate capacity: 100 liters.
Bottom product flow.
With motor and reducer.
Approximate Dimensions:
Width: 750mm.
Height: 1.00 m.
Length: 1.40 m.... |
|
|
 |
200 liter stainless steel jacketed paddle mixer.
With inferior product flow.... |
|
|
 |
Brand: Sew Eurodrive
Blade mixer.
Carbon steel.
With motor and reducer.... |
|
|
 |
Industrial mixer for biscuit.
Blade mixer.
Tipping system.
... |
|
|
 |
Masseira Mixer.
For 1000 kg.
With 2 axes.
Dimensions:
Width: 1,45 m.
Height: 1,80 m.
Length: 3 m.... |
|
|
 |
Brand: Star Machine
Stainless steel paddle mixer.
With carbon steel structure.
Manufacturer: Star Machine.
Approximate capacity: 600 kg.
With screw conveyor in stainless steel.
With scales for weighing the ingredients.
Year: 2019.... |
|
|
 |
Industrial blades mixer.
Capacity: 150 liters.
Used to mix powders and other products.
There is output for the product underneath the mixer.
Stainless steel interior.
With motor and reducer.... |
|
|
 |
Stainless steel horizontal paddle mixer.
Manufacturer: BRAVA ECO PROJETOS ESPECIAIS.
Approximate capacity: 200 liters.
WEG W22 3 HP motor.
Voltage: 380 V.
Approximate internal dimensions of the bowl:
Total height / depth: 620 mm.
... |
|
|
 |
Brand: Consolid
Blade mixer.
Brand: Consolid.
Model: MH - 300.
Made of AISI 304 stainless steel.
With sanitary polish finish.
Horizontal Mixer.
Brand: Consolid.
Model: MH300.
Capacity: 300 Liters.
Stainless Steel 304, polished sanitary fin... |
|
|
 |
Brand: Bonsucesso
- Capacity: 1500 l of mixer and 500 liters of silo approximately.
- The blade mixer is coupled to a lower outlet mezzanine, or silo of the product,
For intermediate transport and storage (silo) for threads
Carriers.
- The equipment has mo... |
|
|
 |
Brand: Claumaq
Mixer.
Brand: Claumaq.
Stainless steel internal tank, shaft and spatula
Capacity: 100 kg.
Measures: 1.80 m x 1.00 m x 1.54 m.
... |
|
|
 |
Brand: Imarvil
All stainless steel horizontal mixer with 300 litres spray.
With 12 Blades in stainless steel 10 mm thick each.
With engine, gearbox and reservoir tank.
External measures.
Width: 860 mm.
height: 1400 mm.
length: 2000 mm.
internal me... |
|
|
 |
Brand: Consolid
Components: Bonfiglioli, Metaltex, WAMGROUP, WEG
Powder blender mixer.
Brand: Consolid.
Model: MH - 50 L.
Average production: 200 kg per hour.
Condition: New never used.
Type: Horizontal blade blender.
With a capacity of 50 liters or 40 kg (d = 0.8), made of stainless steel AISI-3... |
|
|
 |
Brand: Atlas Copco, Beltools, Bonsucesso, Serpack
Complete plant for mixing food products.
Composed by:
- Industrial paddle mixer with output silo mezzanine.
Manufacturer: Bonsucesso.
Approximate mixer capacity: 1,500 liters.
Approximate silo capacity: 500 liters.
Approximate dimen... |
|
|
 |
Brand: Bonsucesso
Stainless steel horizontal mixer with paddle mixing system.
Manufacturer: Bonsucesso.
Volume: 700 L.
Model: BMI 500.
Engine: 10 hp.
Worked with vitamin pre-mix for animal nutrition.
Production in the process: 7,500 kg per hour.... |
|
|
 |
Brand: Bonsucesso
Industrial paddle mixer.
Brand: Bonsucesso.
Litration: 1,500 L.
Average product capacity: 1,200 L.
Silo: approximately 500 L.
Height: 2,90 m.
Total length: 4.30 m.
Width: 1.15 m.
Engine 7.5 CV Reducer motor SK 15/31 IEC 63.... |
|
|
 |
Brand: Bonsucesso
Industrial paddle mixer.
Litration: 1000 L.
Brand: Bonsucesso.
Stainless steel.
Bottom product outlet.... |
|
|
 |
Horizontal mixer.
Blade mixer, with three independent sections.
Stainless steel equipment with acrylic doors.
Dimensions: 1.60 m x 350 m.... |
|
|
 |
Brand: JHM
Line for the production of cheese bread.
Composed by:
Stainless steel blade mixer.
Capacity: 400 KG.
With mezzanine in stainless steel.
Wire cut dripping machine.
Brand: JHM.
Capacity: 400 kg / h.... |
|
|
 |
Brand: Klainox
Overhead paddle mixer in stainless steel near Mint.
Capacity: 300 litres.
Brand: Klain.
Model: MK-300.... |
|
|
 |
Brand: Fapack
Crushing machine.
Stainless steel mixer.
Extruder.
Departure table.
Extrusion molds.
Manual cutting tables.
Customizing presses.
FlowPack wrapping machine with datador.
Xilincadora.... |
|
|
 |
Industrial mixer for paddle mixer powders.
Capacity: 500 kg.... |
|
|
|
|
