 Vibrating screen
Main brands:
Águia Inox, BTZ, Consolid, Mavi, Mineraltec, MVL
|
| Vibrating screen |
A vibrating sieve, also known as a circular vibrating sieve or linear vibrating sieve, is a piece of equipment used in industry to separate solid particles of different sizes. It plays a crucial role in classification and sieving processes, being applied in various industries, such as food, pharmaceutical, chemical, mineral, among others. Let’s explore what a vibrating sieve is for and how it works:
What is it for:
Sieving Materials: The main function of a vibrating sieve is to sieving solid materials, separating them according to their sizes or specific characteristics.
Particle Classification: It classifies solid particles into different fractions based on size, allowing the production of products with the desired particle size.
Impurity Removal: In industrial processes, the vibrating screen can be used to remove impurities, such as unwanted large pieces, from granulated products.
Preparation of Materials: In the food industry, for example, vibrating sieves are often used to prepare ingredients, separate powders or granulates, and ensure the quality of the final product.
How it works:
Basic Structure:
The vibrating sieve is composed of a structure that supports one or more screens or meshes. These screens are responsible for separating particles.
Vibrating Mechanism:
The sieve is equipped with a vibrating mechanism that generates oscillatory or linear movements in the screens. This vibratory movement is fundamental to the sieving process.
Material Feeding:
The material to be screened is fed into the vibrating screen, usually at the top of the machine.
Layer Sieving:
The vibrating movement causes the material to be distributed evenly over the screen. Smaller particles pass through the mesh spaces, while larger ones are retained.
Fraction Separator:
As the material moves over the vibrating screen, different fractions are separated and collected at different outlets. This allows classification by particle size.
Amplitude and Frequency Adjustment:
On many vibrating screens, it is possible to adjust the amplitude and frequency of vibrations, allowing the screening process to be adapted to different types of materials and classification requirements.
Disposal of Unwanted Products:
Unwanted particles or contaminants larger than the desired size are discarded into the corresponding outlet.
The vibrating screen is a versatile and effective equipment for screening solid materials in various industries. Its ability to classify materials efficiently makes it essential in many production and quality control processes. |
|
|
|
 |
Brand: Biasinox, Fortress, MVL
Line for manufacturing soft chocolate sprinkles.
Approximate production capacity: 24 tons per month.*
*considering 8 hours of work per day.
Line composed of:
- Stainless steel jacketed pan with internal steam system.
With carbon steel st... |
|
|
 |
Brand: MVL
Stainless steel horizontal vibrating screen.
Manufacturer/brand: MVL.
Model: P.H 1500 X 600 1.D.
With perforated stainless steel plate with 0.9 mm and 0.6 mm openings.
It has feeding and discharge nozzles, and a drawer-type deck fixing sy... |
|
|
 |
Brand: MVL
Components: Donar
Stainless steel vibrating sieve for continuous sieving.
The equipment has 4 outlets for sieved product per screen set level.
Equipment dimensions:
Possible manufacturer brand: MVL Donar vibrating machines.
Approximate length of the useful... |
|
|
 |
Brand: Águia Inox
Vibrating filter sieve.
Manufacturer / brand: Águia Inox.
Model: FBO20.
Approximate capacity: 20,000 liters per hour.
Year: 2018.
Empty weight: 200 kg.
To filter the fine casein present in the whey from cheese processing, the whey p... |
|
|
 |
Rotary sieve for separating materials.
Estimated production capacity: 100 tons per hour depending on the material.
It comes with a sieve and 2 conveyors for input and output of raw materials.
This industrial sieve is a robust and effective s... |
|
|
 |
Flour transport system.
To transport flour from the silo to the scales.
With control panel, vibrating sieve and flour dispenser.... |
|
|
 |
Brand: Dedini
Silos complete with structure / system for receiving, storing and transporting flour.
Year: 2003.
They were used in the food industry for the production of biscuits.
6 flour silos of 25 tons each.
5 silos of 165 m³ each.
1 sugar silo o... |
|
|
 |
Brand: Mineraltec
Components: WEG
Stainless steel vibrating sieve.
Based on carbon steel.
Manufacturer: Mineraltec.
Model: MPVS1203.
Engine: WEG 4 C.V.
Voltage: 220 / 380 V.
Inner diameter: 1114 mm.
Dimensions for transport: (Height x Width x Length)
1600mm x ... |
|
|
 |
Stainless steel vibrating screen.
External measures: 1.40 m high x 1.00 m wide x 2.20 m long.... |
|
|
 |
Stainless steel vibrating screen.
With vibrator.
Overall height: 125 cm.
Width: 84 cm.
Funnel exit height to the floor: 84 cm.
Diameter screen hole area: 75.5 cm.
Total screen diameter: 77 cm.
Funnel diameter: 20 cm.... |
|
|
 |
Brand: Consolid
Mixer for powdered products with screw conveyor, receiving silo, centrifugal sieve and mezzanine.
Automated mixing system for pre-mixing cakes and other products consisting of:
- Horizontal mixer in AISI 304 stainless steel.
Manufacturer / b... |
|
|
 |
Rotary sieve.... |
|
|
 |
Brand: MVL
Vibrating sieve with stainless steel screens.
Manufacturer/brand: MVL.
It was used to separate impurities smaller than the seeds.
Its productivity depends on the product.
In the case of sesame, the approximate capacity was up to 220 kg / ... |
|
|
 |
Brand: MVL
Vibrating sieve.
It was used for tapioca.
Approximate capacity: 2000 kg / hour.... |
|
|
 |
Brand: Mavi
Vibrating sieve type Rotopen 750 - 1 and 10 - 6 / V.
Brand: Mavi.
Vibrating bucket with useful Ø 750 mm
std frame for screen tensioning, with outlet mouth
Screen opening to be confirmed:
Closed construction with removable cover;
Col... |
|
|
 |
Brand: BTZ
Stainless steel sieve.
Brand: BTZ.
Two units, to be confirmed.... |
|
|
 |
Complete industry company for the recovery of plastic materials such as PP, HDPE and LDPE.
It has:
1 extruder 120 mm.
With hydraulic head.
Approximate capacity: 420 kg/h.
Engine power: 125hp.
1 extruder 120 mm.
With hydraulic head.
Appr... |
|
|
 |
Stainless steel vibrating screen.... |
|
|
 |
Conveyor belt.
Without motor.
Measures 1.20 mm length x 0.59 mm width x 0.96 mm height.... |
|
|
|
|
